Product Detail

Features

• ROAR approved
• Works with 4 pole brushless motor, a full sensor mode when paired with HOBBYWING motor
• 10 different programmable profiles available through LCD program box or OTA Module, or Tunalyzer
• Fully adjustable brake and throttle functions
• LiPo Low Voltage Cut off
• ESC thermal overheat protection
• Motor thermal overheat protection
• Remote On/Off feature
• '1-degree' Precision throttle and brake control
• Coast Control (patent pending*)
• Drive Frequency Control
• Brake Frequency Control
• Boost Timing control and options for Modified racing
• Turbo Timing control and option for Modified racing
• Ultra-Low-resistance circuitry
• ROAR-approved software including Zero-timing
• Smallest footprint and height possible with current technology to fit within even more tighter space of a vehicle.
• 12-gauge high-quality power wires
• Powerful external capacitor board
• HOBBYWING Over-The-Air Firmware updateable through HOBBYWING programmer: Tunlayzer or OTA (purchased separately)
• The most advanced brushless ESC has proven by World Champ.competitions worldwide.

Contents

• XR10 PRO ESC w/ a cooling fan
• (2) Input wires 12AWG-200mm
• (3) Output wires 12AWG-200mm
• (2) x cooling fan (comes with one back-up fan)
• Dual capacitors
• Decals
• Bonus parts: heat tubes, double tape, nylon cable zap traps
• User's manual

Specifications

• Type Scale: 1/10th Brushless Sensored ESC
• Cont./Peak Current: 160A/1200A
• Power input: 2-3S LiPo/4-9 Cell NiMH
• BEC output: 6V/7.4V Switchable, Continuous Current of 4A (Switch-mode)
• Wire input: Black-12AWG-200mm*2
• Wire output: Black-12AWG-200mm*3
• Size: 37.5x30.9x31.6mm (w/Fan & Fan Shroud)
• Weight: 95g (w/ Wires)
• Fan dimensions: 25.0x25.0x10.0mm
• Fan voltage range: Powered by the stable BEC voltage of 6V/7.2V
